Dynapac's range of small and medium-size vibratory rollers are used to compact all types of soil with the exception of rockfill. The rollers are suitable for most types of road construction, airfields, dam construction, harbour projects and industrial constructions. Heavy-size vibratory rollers are used for a very wide range of applications. The thickness and grade of the drum's steel are adapted for compacting rockfill, although vibratory rollers are also known for their excellent performance on other types of fill. A special version with a padfoot drum (PD) is available for compacting cohesive soils.
Dynapac's double drum asphalt roller range features everything from the most compact equipment for repair jobs to large machines for the biggest sites. Vibration dampened platforms, swivel seats for better visibility, logically sorted controls and Roll Over Protective Structures (ROPS) all contribute to the maneuverability, operator ergonomics and safety.
The combi-versions are equipped with four rubber tyres at the rear instead of a drum. The rubber wheels are driven in pairs by separate propulsion motors, thus minimising the risk of damaging newly laid asphalt compound when making sharp turns. The rubber wheels ensure a denser and smoother surface on the asphalt, a feature that is sometimes required.
The Dynapac CS1400 is a modern, articulated static threedrum roller with the same static linear load and drum diameter on all drums. The roller covers the asphalt mat with its full width. The Dynapac CS1400 is used primarily to compact asphalt when the course has a typical thickness of up to 50 mm, depending on the stiffness of the asphalt compound and the prevailing weather conditions. The machine is suitable for medium-size and large-size applications. It is ideal for use in areas where the ground should not be vibrated, such as in areas close to old buildings and on bridges.
Dynapac has a complete range of pneumatic tyred rollers. All have standard features offering high performance, simplicity and versatility. The CP1200 has an exclusive Modular Ballast System comprising sealed ballast containers to allow exact visual control of wheel loads. The roller is used to compact asphalt for sealing purposes. It is also used to compact base, sub-base and stabilized soil. CP2100 and CP2700 are used mainly in conjunction with other asphalt rollers for surface sealing. Due to their heavy weight, they are also used for soil compaction.
The Dynapac CT3000 tamping compactor has been designed to efficiently achieve specified densities on cohesive and semi-cohesive soils. With an operating weight of 22 tons, and an average production capacity of 900 cubic meters per hour, the Dynapac CT3000 is ideal on projects such as highways, dams and airport runways where largevolume earthwork is required.
Operating Mass: 10600 kg
Static linear load: 29.1 kg/cm
Drum width: 2130 mm
Operating Mass: 2360 kg
SLL (front/rear): 10.6/ 11.4 kg/cm
Drum width: 1070 mm
Operating Mass: 2600 kg
SLL (front/rear): 10.5/ 11.3 kg/cm
Drum width: 1200 mm
Operating Mass: 3900 kg
SLL (front/rear): 14.5/ 15.4 kg/cm
Drum width: 1300 mm
