| H4. Dumping height | |
|---|---|
| K. Ground clearance | |
| L2. Length, hopper |
| Masses | |
| Weight | 8500000 g |
|---|---|
| Traction | |
| Paving speed | 0 - 32 m/min |
| Maximum paving speed | m/s |
| Transport speed | 5 m/s |
| Engine / Drive | |
| Manufacturer | Deutz |
| Model | TD 2011 L04 |
| Manufacturer / Model | Deutz TD 2011 L04 |
| Rated power | 52000 W |
| Rated power | 71 W |
| Rated power @ | 2300 W |
| Rated power | 52000 W (71 W) @ 2300 W |
| Emissions according to | EU 3A/Tier 3 |
| Electrical system | 2 x 12V, 72Ah |
| Alternative Engine | |
| Manufacturer / Model | |
| Operation | |
| Operator console | Shiftable left/right |
| Operator seat | Adjustable, comfortable, hydraulically sprung seat |
| Conveyor | |
| Conveyor type | Dual bar feeder |
| Conveyor width | 350 mm |
| Conveyor control | On/off switch, running direction of each side independently reversible |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Wheeled pavers | D299000714 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Wheeled pavers | D299000818 | old version (conveyor bars at chain) | ||
| Wheeled pavers | D299000858 | S/N: 874300 ff, double quantity of conveyor bars |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Wheeled pavers | D299000817 | up to S/N: 874299 and 8750099 | ||
| Wheeled pavers | D299000859 | from S/N: 874300 and 8750100 | ||
| Wheeled pavers | D299000824 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Wheeled pavers | D299000511 | old version | ||
| Wheeled pavers | D299000856 | COMIII, S/N: 8750100 ff |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Wheeled pavers | 4812031435 | up to S/N: 874219 | ||
| Wheeled pavers | D299000860 | from S/N: 874300 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Wheeled pavers | D299000512 | old version | ||
| Wheeled pavers | D299000857 | COMIII, S/N: 8750100 ff |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Wheeled pavers | D299000755 | Deutz BF4L2011, Machine s/n 874125 - 874145, 874147, 874149 -874152, 874155 - 874157, 874159, 874163, COMII | ||
| Wheeled pavers | D299000586 | Deutz BF4L2011, Machine s/n 874146,874148, 874153, 874154, 874158, 874160-874162, 874164-874176, 874179-874180, 874182-874188, 874190, 874191, 874193-874198, 874201, 874202, 874204, COMII | ||
| Wheeled pavers | D299000632 | Deutz BF4L2011, Machine s/n 874177, 874178, 874181, 874189, 874192, 874199, 874200, 874203, from 874205, COMII | ||
| Wheeled pavers | D299000755 | Deutz TD2011 L04, Maschine s/n from 874300 - 874307 | ||
| Wheeled pavers | 4812025554 | Deutz TD2011 L04, Machine s/n from 874308 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Wheeled pavers | D299000473 | Deutz BF4L2011, Machine s/n 874125 - 874145, 874147, 874149 -874152, 874155 - 874157, 874159, 874163, COMII | ||
| Wheeled pavers | D299000585 | Deutz BF4L2011, Machine s/n 874146,874148, 874153, 874154, 874158, 874160-874162, 874164-874176, 874179-874180, 874182-874188, 874190, 874191, 874193-874198, 874201, 874202, 874204, COMII | ||
| Wheeled pavers | D299000630 | Deutz BF4L2011, Machine s/n 874177, 874178, 874181, 874189, 874192, 874199, 874200, 874203, from 874205, COMII |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Wheeled pavers | D299000754 | Deutz BF4L2011, Machine s/n 874125 - 874145, 874147, 874149 -874152, 874155 - 874157, 874159, 874163, COMII | ||
| Wheeled pavers | D299000586 | Deutz BF4L2011, Machine s/n 874146,874148, 874153, 874154, 874158, 874160-874162, 874164-874176, 874179-874180, 874182-874188, 874190, 874191, 874193-874198, 874201, 874202, 874204, COMII | ||
| Wheeled pavers | D299000631 | Deutz BF4L2011, Machine s/n 874177, 874178, 874181, 874189, 874192, 874199, 874200, 874203, from 874205, COMII | ||
| Wheeled pavers | D299000754 | Deutz TD2011 L04, Maschine s/n from 874300 - 874307 | ||
| Wheeled pavers | D299000754 | Deutz TD2011 L04, Machine s/n from 874308 |
