Dynapac MF2500CS with SW6500 • Dynapac

Dynapac MF2500CS with SW6500 Mobile matere

Min sammenligning

Erfaring
Bilder
Dimensjoner

Blueprint sett fra siden Dynapac MF2500CS with SW6500

Blueprint sett ovenfra Dynapac MF2500CS with SW6500

A. Akselspor	3.97 m
B. Clearance, Swing conveyor (min.)	1,1 m
B1. Bredde, maks	3.35 m
B2. Bredde, standard	2.55 m
B3. Bredde, midtpunkt av spor	2.09 m
C1. Sporbredde	320 mm
D. Clearance, Swing conveyor (max.)	3,7 m
E. Swing conveyor material drop height	4,15 m
H1. Høyde, maks.	5 m
H2. Høyde	4 m
H3. Height, transport	3.10 m
H4. Dumping height	530 mm
L1. Lengde	15.3 m
L3. Lengde, trakt	2.25 m

Being the only 2.5 meter feeder on the market, the Dynapac MF2500CS combines easy and cost effective transport - no permissions needed - with impressive feeding capacity. With the unique Dynapac SW6500 a standard MF2500CS can be transformed into a swinging feeder in less than 30 minutes. The hydraulic jacks make the mounting easy and convenient. With a swing angle of 55° and a side reach of 3.4m, the Dynapac feeder is the perfect machine for a lot of applications.

Standard legge bredde: N/A

Maks legge bredde: N/A

Maks legge tykkelse: N/A

Teoretisk kapasitet av kapasitet: N/A

Tekniske data

Masser
Transport mass	24.50 t
Trekkkraft
Operating speed, max	25 m/min
Transporthastighet, maks	4 km/h
Motor
Produsent/Modell	Cummins QSB 6.7-C220
Maks effekt, SAE J1995	164 kW (220 hp ) @ 2200 rpm
Elektrisk system	24 V
Drivstofftank	300 l
Utslipp iht	EU Stage III / EPA Tier 3
Alternative motor
Produsent/Modell	Cummins B 6.7-C225
Maks effekt, SAE J1995	168 kW (225 hp) @ 2200 rpm
Elektrisk system	24 V
Utslipp iht	EU Stage V / EPA Tier 4f
Drivstofftank	360 l
Medbringer
Transportør type	Rubber belt on two chains, mounted with metal stiffeners
Conveyor speed	Constantly variable
Bredde	1200 mm
Feeding height (max/min)	4.15 m / 1.10 m
Feed capacity	4000 t/h
Feed capacity, optional swing conveyor	2000 t/h

Service kits

Conveyor belt rail kit

Kategori	Underkategori	P/N	Annen informasjon
	Mobile matere	4812009720

Conveyor guide kit

Kategori	Underkategori	P/N	Annen informasjon
	Mobile matere	4812009718

Hopper rubber kit, reinforced, hydr. front flap

Kategori	Underkategori	P/N	Annen informasjon
	Mobile matere	4812007263	With steel rops. Version 1
	Mobile matere	4812015980	With steel rops. Version 2

Rubber pad kit

Kategori	Underkategori	P/N	Annen informasjon
	Mobile matere	4812008959	For long track frame
	Mobile matere	4812008960	For short track frame

Scraper kit

Kategori	Underkategori	P/N	Annen informasjon
	Mobile matere	4812009723

Service kit 1000h

Kategori	Underkategori	P/N	Annen informasjon
	Mobile matere	4812046970	TIER 4
	Mobile matere	4812046969	TIER 3

Service kit 500h

Underkategori	P/N	Annen informasjon
Mobile matere	4812042198	TIER 4
Mobile matere	4812043984	TIER 4
Mobile matere	4700691229	TIER 3
Mobile matere	4812043983	TIER 3
