| H. Height | 740 mm |
|---|---|
| H1. Height | 930 mm |
| H2. Height | 1080 mm |
| L. Length | 1460 mm |
| L1. Length | 650 mm |
| W. Basic plate width | 400 mm |
| Masses | |
| Basic mass | 147 kg |
|---|---|
| Operating mass | 150 kg |
| Operating mass (W2) | kg |
| Traction | |
| Max. gradeability | 30 % |
| Max. working speed | 25 m/min |
| Compaction | |
| Amplitude | 1.55 mm |
| Centrifugal force | 25 kN |
| Frequency | 85 Hz |
| Water tank | l |
| Water tank volume | 12 l |
| Engine | |
| Manufacturer/Model | Hatz 1B20 |
| Emissions according to | EU Stage V / non US EPA |
| Rated power | kW |
| Number of cylinders | 1 |
| Fuel consumption /h, avg. | 0 m3 |
| Fuel tank capacity | 3 l |
| Power | 3.1 kW @ 3000 rpm |
Standard
Optional
