| A. Axle track | 3.95 m |
|---|---|
| B1. Width, max. | 3.55 m |
| B2. Width, standard | 2.55 m |
| B3. Width, center of tracks | 2.09 m |
| C1. Track width | 320 mm |
| H1. Height, max. | 5 m |
| H2. Height, transport | 3.10 m |
| H3. Height | 580 mm |
| L1. Length | 9.25 m |
| L3. Length, hopper | 2.25 m |
| Masses | |
| Transport mass | 24.50 t |
|---|---|
| Transport Weight with SW6500 | |
| Traction | |
| Transport speed | km/h |
| Operating speed, max | 25 m/min |
| Transport speed, max | 4 km/h |
| Engine / Drive | |
| Manufacturer / Model | Cummins QSB 6.7-C220 |
| After treatment | |
| Rated power, SAE J1995 | 164 kW (220 hp ) @ 2200 rpm |
| Peak power | |
| DEF tank capacity | l |
| Average fuel conumption | |
| Electrical system | 24 V |
| Alternative Engine | |
| Manufacturer / Model | Cummins B 6.7-C225 |
| After treatment | |
| Rated power, SAE J1995 | |
| Peak power | |
| Alternative Engine | |
| Peak power | |
| Fuel tank capacity | |
| Average fuel conumption | |
| Conveyor | |
| Conveyor type | Rubber belt on two chains, mounted with metal stiffeners |
| Conveyor speed | Constantly variable |
| Conveyor width | 1.20 m |
| Feeding height | 2.18 m |
| Feed capacity | 4000 t/h |
| Feed capacity, optional swing conveyor | 2000 t/h |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Paving | Mobile feeders | 4812009720 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Paving | Mobile feeders | 4812009718 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Paving | Mobile feeders | 4812007263 | With steel rops. Version 1 | |
| Paving | Mobile feeders | 4812015980 | With steel rops. Version 2 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Paving | Mobile feeders | 4812008959 | For long track frame | |
| Paving | Mobile feeders | 4812008960 | For short track frame |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Paving | Mobile feeders | 4812009723 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Paving | Mobile feeders | 4812046970 | TIER 4 | |
| Paving | Mobile feeders | 4812046969 | TIER 3 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Paving | Mobile feeders | 4812042198 | TIER 4 | |
| Paving | Mobile feeders | 4812043984 | TIER 4 | |
| Paving | Mobile feeders | 4700691229 | TIER 3 | |
| Paving | Mobile feeders | 4812043983 | TIER 3 |
