DYNAPAC F1250CS Plus Compact Paver & RC360 Remote - A double portion of power and precision

22 May 2023

Press release, Story, Paving

DYNAPAC F1250CS Plus Compact Paver & RC360 Remote - New Model available

Paving in urban areas comes with its own set of challenges and demands on machinery: tight spaces, weight limits, underground pipes, and old, exposed materials such as cobblestones require well-thought-out and innovative solutions. The popular Compact Paver F1250CS is now launched as a new model with a number of improvements as the Dynapac F1250CS Plus. The modifications to the previous model are aimed at even higher protection and comfort of the operator.

New features

The Compact Paver with its best-in-class screed quality and optional RC360 remote control ensures that every surface from walkways and bike paths to underground garages and alleys, get the desired results safely, economically, and with maximum operational comfort. One of the most significant improvements of the new model are the redesigned side engine doors. These doors are not only sleek and modern in appearance, but they are also designed to direct outflowing air away from the screed operator. This feature promotes a more comfortable and safe working environment, as well as better overall paving results. Another exciting update to the asphalt paver is the optional hydraulic auger height adjustment. This feature provides greater operator comfort, allowing for easier and more precise height adjustments. This increased level of control ensures a smoother and more accurate paving experience. Finally, this new asphalt paver includes material flow optimization through proportional control of auger and conveyor. This advanced technology regulates the transfer amount of material fully automatically, ensuring a consistent and efficient flow of material throughout the paving process.

Small size – big impact

The need for compact pavers that can perform a multitude of urban applications and jobs has continued to grow. With the Compact Paver and remote control RC 360, Dynapac is filling this fast-moving market. Small, yet powerful, the F1250CS Plus is ideal for areas where high-quality results between 0.5 up to 3.5m are needed. Aside from being robust, flexible, and equipped with the future-ready technology today’s paving jobs require, it also comes with exceptional screed quality that ensures perfect mat quality even when job sites have complex or challenging requirements. When paired with the unique remote- control RC 360, operators can position themselves wherever they want and enjoy new freedom, mobility, and safety without being tied to dashboard controls.

A screed that leaves no wish unfulfilled

The F1250CS Plus is made even more exceptional due to its high-end screed that is available in both gas- and electrically heated versions. This offer is unique in the market and provides both operators and planners with greater flexibility and onsite results. The compact and powerful V2400 has the same quality and performance as its larger "brothers" and comes with a handy extension box for greater widths. Its robust tamper and vibratory plate ensure ideal compaction while reducing the number of roller passes. The high-performance screed, combined with the compact vehicle dimensions and generous material handling system makes the F1250CS Plus ideal for a wide range of applications. As an added benefit, this Compact Paver can pave below zero, thus increasing refurbishment job efficiency, since the paver can drive out of the milling cut, allowing the screed to pave a smooth finish.

Thanks to the multiple adjustments, like the angle of attack and the deep bottom plates, the screed delivers an excellent pre-compaction and a smooth surface, even with thick layers. The quick coupling means setup and operation are always easy and ready to go.

The RC360 Remote: A new era of mobility and performance

With the addition of the RC360 remote control, the F1250CS Plus is given an even greater performance spectrum that opens up new opportunities in paver operation, especially in tight spaces. By using it, the operator can control the paver from a point that offers the lowest asphalt fumes while providing maximum visibility and results. The RC360 remote also comes with a case and charging devices with a mechanical connector for external supply. Its adjustable shoulder straps have been ergonomically designed for more wearing comfort during the entire workday.

Ensuring a high level of safety when working at a greater distance is of paramount importance on any job. A built-in safety feature is automatic engine shutdown when the operator moves further than 10m away from the paver. The paver also automatically stops when the remote is tilted higher than a 45° angle. The remote function comes with the added safety feature of distancing the operator from fumes while fulfilling local regulations.

Comfort, convenience and control

The lean dashboard is intuitive and self-explanatory with toggle switches and colored display, making it ideal for changing crews to understand and operate. The entire platform can be folded up for transport or paving situations close to a wall, which saves both handling and time. The convenient backrest offers additional comfort and comes with a lockable storage compartment for personal items. Thanks to the ergonomic side shields, their height, and angle are adjustable with only one crank. The crank is placed on top of the side shield creating a comfortable, central, and safe workplace for the screed operator. The F120CS Plus also comes with a USB, 24V/DC and a 230V/AC socket to fulfill everyday needs on the job site. The F1250C Plus is equipped with the very latest in efficient and emission-reducing diesel motor technology. A 4 cylinder 54 kW Deutz engine is also available as T3/Stage III and T4/Stage V to meet emissions requirements in the various markets.
