| A. Wheelbase | 2200 mm |
|---|---|
| B1. Width, front | 1870 mm |
| B2. Width, rear | 1530 mm |
| D. Drum diameter | 1219 mm |
| H1. Height, with ROPS | 2700 mm |
| K1. Ground clearance | 360 mm |
| K2. Curb clearance | 360 mm |
| L. Length | 4510 mm |
| O1. Overhang, right | 95 mm |
| O2. Overhang, left | 95 mm |
| R1. Turning radius, outside | 4580 mm |
| R2. Turning radius, inside | 2900 mm |
| S. Drum shell thickness | 22 mm |
| W. Drum width | 1676 mm |
| α. Steering angle | ±33° |
A tool to monitor and control their machine fleet efficiently and conveniently.
Big fuel savings with Eco!
Any Dynapac product equipped with a Stage IV engine, is not only compliant with the latest emission stage but is also contributing to great fuel cost savings.
| Masses | |
| Operating mass (incl. ROPS) | 6500 kg |
|---|---|
| Module mass (front/rear) | |
| Max. operating mass | 7200 kg |
| Traction | |
| Speed range (Dual/TC/AS) | 0-10 km/h |
| Max. theoretical gradeability | 56 % |
| Vertical oscillation | ±9º |
| Engine / Drive | |
| Manufacturer/Model | Kubota V 3307 CR-TE4 (Stage IIIB/T4) |
| Type | Water cooled turbo diesel |
| Rated power, SAE J1995 | |
| Fuel tank capacity | 117 l |
| Hydraulic system | |
| Driving | Hydrostatic with a traction pump supplying two parallel connected motors, one on rear axle and one on drum. |
| Vibration | Hydrostatic with a vibration pump supplying a motor connected to the eccentric axle generating the vibrations. |
| Steering | Mechanical-hydraulic with steering valve supplying the steering cylinder. Steering angle is proportional to steering wheel. |
| Service brake | Hydrostatic in forward and reverse lever. |
| Parking/ Emergency brake |
Failsafe multidisc brake in rear axle and front drum motor. |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Compaction | Single drum vibratory rollers | 4812159465 | Cummins T3 oil inc | |
| Compaction | Single drum vibratory rollers | 4812159466 | Cummins T3 No oil inc |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Compaction | Single drum vibratory rollers | 4812159468 | Cummins T3 oil inc |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Compaction | Single drum vibratory rollers | 4812159463 | Cummins T3 oil inc | |
| Compaction | Single drum vibratory rollers | 4812159464 | Cummins T3 No oil inc |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Compaction | Single drum vibratory rollers | 4812159462 | Cummins T3 oil inc |
Standard
Back up alarm, Battery switch (std), Brake release, Cup and can holder, Differential lock (limited slip), Drive control (right side), Drum drive, ECO mode, Emergency stop, Engine 55 kW (StageIIIB/Tier4final), Engine hood (lockable), Fuel level display, High mounted exhaust pipe, Horn, Hour meter display, Hydraulic checkpoints, Hydraulic fluid filter ("spin-on"), Hydraulic fluid (mineral), Interlock, Key (starter), Lifting points, Lifting points for jack, Manuals (Operation & Maintenance), Manuals (Spare parts catalogue), Operator's platform (rubber mouted), Operator's station (fixed), Parking brake, ROPS (fixed), Seat (adjustable), Seat belt 3", Storage box (on platform), Storage for laminated manuals, Tie down points, Vandal cover (instrument panel), Warning lights (brake, engine oil pressure, engine oil temperature, engine diagnostics, low charge, low fuel level)
