| A. Axle track | 2900 mm |
|---|---|
| B1. Width, max. | 3400 mm |
| B2. Width, standard | 2550 mm |
| B3. Width, center of tracks | 1992 mm |
| C1. Track width | 320 mm |
| H1. Height, max. | 3900 mm |
| H2. Height, transport | 3100 mm |
| H3. Height | 492 mm |
| L1. Length | 6145 mm |
| L3. Length, hopper | 2123 mm |
A tool to monitor and control their machine fleet efficiently and conveniently.
| Masses | |
| Basic weight (incl. standard screed) | 18 t |
|---|---|
| Traction | |
| Maximum paving speed | 30 m/min |
| Transport speed | 4.0 km/h |
| Engine / Drive | |
| Manufacturer/Model | |
| Emissions according to | Stage IIIA (Tier 3) |
| Rated power, SAE J1995 | 110 kW @2,200 rpm with stepless rpm control |
| Electrical system | 24 V |
| Fuel tank capacity | 337 l |
| Alternative Engine | |
| Manufacturer | |
| Model | |
| Manufacturer/Model | |
| Rated power | |
| Peak Power | |
| DEF tank capacity | |
| Fuel tank capacity | |
| Average fuel conumption | |
| After treatment | |
| Conveyor | |
| Conveyor type | Dual bar feeder |
| Conveyor width | 2 x 655 mm |
| Conveyor control | Automatic with limit switches |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Paving | Screeds | 4812017377 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Paving | Screeds | 4812012551 | Hardox 400 |
