| A. Wheelbase | |
|---|---|
| B. Width | |
| C. Curb clearance | 400 mm |
| D. Drum diameter | 1220 mm |
| H1. Height, with ROPS/cab | 3200 mm |
| H2. Height, w/o ROPS/cab | 2450 mm |
| K. Ground clearance | 282 mm |
| L. Length | 4340 mm |
| R1. Turning radius, outside | 6500 mm |
| R2. Turning radius, inside | 4900 mm |
| S. Drum shell thickness | 17 mm |
| W. Drum width | 1690 mm |
| α. Steering angle | ±29° |
| Masses | |
| Max. operating mass | 9,600 kg |
|---|---|
| Operating mass (incl. ROPS) | 9,200 kg |
| Module mass (front/rear) | 4600/4600 kg |
| Traction | |
| Speed range | 0-12 km/h (Working/Travel) |
| Vertical oscillation | ±7° |
| Max. theoretical gradeability | 39 % |
| Engine / Drive | |
| Fuel tank capacity | l |
| Alternative Engine | |
| Manufacturer / Model | KOEL |
| Type | Water cooled Diesel |
| Rated power, SAE J1995 | 54.8 kW (74.5) @ 2200rpm |
| Fuel tank capacity | 180 l |
| Emission stage | CEV-V |
| Alternative Engine | |
| Manufacturer / Model | |
| Hydraulic system | |
| Driving | Axial piston pump with variable displacement. Axial piston motor with variable displacement. |
| Vibration | Axial piston pump with variable displacement. Axial piston motor with fixed displacement. |
| Steering | Gear pump with constant displacement. |
| Service brake | Hydrostatic in forward and reverse lever. |
| Parking/Emergency brake | Failsafe multidisc brake. |
| Compaction - Oscillation | |
| Oscillation frequency | Hz |
Standard
Optional
