PAVIMENTAÇÃO

Dynapac F1250CS Compact pavers

  • Experiência
  • Imagem
  • Dimensões
A. Axle track 1400 mm
B1. Width, max. 2820 mm
B2. Width, standard 1430 mm
B3. Largura, entre esteiras 940 mm
C1. Largura da sapata 200 mm
H1. Altura, máx.
H2. Altura, transporte 2020 mm
L1. Length, total 4760 mm
L2. Comprimento, transporte 4450 mm
L3. Comprimento, silo 1640 mm
Discontinued false
Whenever high quality results between 0.5 up to 3.5m are needed, the Dynapac F1250CS is the right choice. This powerful paver with its remarkable screed ensures a perfect mat quality, even when jobsites has challenging requirements. Equipped with the unique remote control RC 360, the paving job becomes even safer and smarter, since the the operator is not tied to the dashboard. The operator can position himself whereever suitable.
Largura básica de pavimentação: 1,20 m
Esp. Máx. Pavimentação: 3,50 m
Espes. Máx. Camada: 200 mm
Capac. Teór. de Descarga: 300 t/h

Características e Benefícios

Dynapac Eco mode
Eco mode

Big fuel savings with ECO!


Dynapac Stage V / TIER 4f
Stage V / TIER 4f

Any Dynapac product equipped with a Stage IV engine, is not only compliant with the latest emission stage but is also contributing to great fuel cost savings.

Características técnicas

Pesos
Peso (incl. mesa) 7,0 t
Tração
Velocidade de pavimentação up to 27 m/min
Velocidade de transporte 3,3 km/h
Motor
Fabricante/Modelo Deutz TD2.9 L4
Emissões EU Stage V / EPA Tier 4f
Potência nominal 55.4 kW (75 hp) @2200 rpm
Sistema elétrico 2 x 24V, 72 Ah
Tanque de combustível 85 litros
Motor Alternativo
Fabricante/Modelo Deutz TD2.9 L4
Emissões EU Stage III / EPA Tier 3
Potência nominal 54 kW (73hp) @2200 rpm
Sistema elétrico 2 x 24V, 72 Ah
Tanque de combustível 85 litros
Operação
Painel de operação Slidable left/right
Platform Extendable platform
Transportadora
Tipo One splitted, reversible conveyor with center cover
Largura 620 mm
Controle Automatic with limit switches

Kits de Serviço

Auger wear part kit
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812027478 Center drive 380 mm
HIGHWAY PAVERS 4812040657 Outer drive 380 mm
Conveyor chain kit
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812029821 Single quantity of bars
HIGHWAY PAVERS 4812029822 Double quantity of bars
Conveyor drive kit
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812035552
Conveyor guide plate kit
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812225799
Conveyor plate kit
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812016662
Hopper rubber kit, standard, hydr. front flap
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812018438
Hopper rubber kit; standard
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812018441
Reversing roller kit
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812035553
Service kit , 1000H
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812046969 Tier 3
HIGHWAY PAVERS 4812012384 Tier 4i
Service kit , 500H
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4700691229 Tier 3
HIGHWAY PAVERS 4812043983 Tier 3 Including oil
HIGHWAY PAVERS 4812012378 Tier 4i
HIGHWAY PAVERS 4812012382 Tier 4i Including oil
HIGHWAY PAVERS 4812012939 Tier 4F
Service kit , 750H
Categoria Subcategoria P/N Informações Adicionais
HIGHWAY PAVERS 4812012936 Tier 4F

Equipamentos (Standard e opcionais)

Standard

2 front & 2 rear lights, Conventional electrics, , Dashboard with display and toggle switches, Eco Mode, Extendable steps operator platform, Hopper hydraulic separate control, Auger height adjustm., Conveyor reversible (splitted)with limit switches, Ultrasonic sensors auger

Opcional

Back-up alarm, Reduction shoes (0.5 working width), Working widths (3.1m + 3.5m), Emulsion spray equipment with pump and hose dispenser, Fire extinguisher, First aid kit, 4x LED lights, Light for auger compartment, Bio degradable hydraulic oil, Remote steering device, Rotating flashing beacon, Heatable side shields, Special painting,
